1.Configure PPPoE Client WAN Connection)

Setting up a PPPoE VPN on ROS (RouterOS) involves configuring both PPPoE client (for internet connection) and VPN services (like L2TP/IPsec, SSTP, or OpenVPN). Below is a step-by-step guide: First, ensure your router has a working PPPoE connection for internet access.

Steps:

1. Access Winbox → Go to Interfaces.

2. Add PPPoE Client:

   • Click → PPPoE Client.
   • Interface: Select the physical interface (e.g., ether1).
   • User/Password: Enter your ISP credentials.
   • Service Name: (Optional, if required by ISP).
   • Click Apply and OK.

3. Verify Connection:

   • Check IP → Addresses for a new PPPoE-assigned IP.
   • Test internet connectivity via Tools → Ping.

---

Set Up VPN (L2TP/IPsec, SSTP, or OpenVPN)

Choose one of the following VPN types:

Option 1: L2TP/IPsec VPN

1. Enable L2TP Server:

   • Go to PPP → Interface → L2TP Server.
   • Enable Enable.
   • Set Default Profile to default-encryption (or create a new profile).

2. Configure IPsec (for security):

   • Go to IP → IPsec → Enable Proposals with:
     • Encryption: AES-256
     • Hash: SHA-256
     • DH Group: modp2048
   • Add a Peer with:
     • Address: 0.0.0/0
     • Auth Method: PSK (Pre-Shared Key).
     • Enter a strong Secret.

3. Add VPN Users:

   • Go to PPP → Secrets.
   • Add a user with:
     • Name: vpnuser
     • Password: securepassword
     • Service: l2tp
     • Local Address: 168.88.1 (router’s LAN IP).
     • Remote Address: 168.88.100 (VPN client IP).

4. Firewall Rules:

   • Allow IPsec (UDP 500, 4500) and L2TP (UDP 1701):

     /ip firewall filter
     add chain=input protocol=udp dst-port=500,4500,1701 action=accept

---

Option 2: SSTP VPN (for Windows clients)

1. Enable SSTP Server:

   • Go to PPP → Interface → SSTP Server.
   • Enable Enable.
   • Set Certificate (generate one in System → Certificates).

2. Add VPN Users (same as L2TP, but set Service=sstp).

3. Firewall Rules:

   • Allow TCP 443 (SSTP uses HTTPS):

     /ip firewall filter
     add chain=input protocol=tcp dst-port=443 action=accept

---

Option 3: OpenVPN (for cross-platform support)

1. Install OpenVPN Package (if not installed):

   • Download from MikroTik’s Package Repository.
   • Upload via Files and reboot.

2. Configure OpenVPN Server:

   • Go to PPP → Interface → OpenVPN.
   • Set Mode: Server, Protocol: UDP, Port: 1194.
   • Configure Certificate and Auth.

3. Firewall Rules:

   • Allow UDP 1194:

     /ip firewall filter
     add chain=input protocol=udp dst-port=1194 action=accept

---

NAT & Firewall Configuration

Ensure VPN traffic can reach LAN:

1. Masquerade NAT:

   /ip firewall nat
   add chain=srcnat action=masquerade out-interface=pppoe-out1

2. Allow VPN Traffic to LAN:

   /ip firewall filter
   add chain=forward src-address=192.168.88.100 dst-address=192.168.88.0/24 action=accept

---

Test VPN Connection

• Windows: Use VPN settings (L2TP/IPsec or SSTP).
• Android/iOS: Use L2TP/IPsec with PSK.
• OpenVPN: Use .ovpn config file.

---

Troubleshooting

• No Internet on VPN? Check NAT and firewall rules.
• PPPoE not connecting? Verify ISP credentials and physical link.
• VPN drops? Check /log for errors.

---

This setup ensures a secure PPPoE + VPN configuration on MikroTik RouterOS. Let me know if you need help with a specific part!
